1.0
Structure

1.1 Imposed loads

Office areas
4KN/sq m + 1KN/sq m
Plant (general)
7.5KN/sq m

1.2 Dimensional data

Floor to ceiling height
min 2.6m
Raised floor
min 70mm raised floor
Structural grid
600mm x 600mm

2.0
Air conditioning

2.1 VRV system

Fresh air volume
10 litres/second

2.2 Cooling/loads

Lighting
12w/sq m
Small power
25w/sq m
Occupancy
8w/sq m

3.0
Electrical

3.1 Office lighting

Lighting level
LG3 compliant
Luminaires
500 lux

Electrical loading
small power 25w/sq m

3.2 Passenger lifts

Number
3 (including 1 fire lift)
Size
8 person/530 kg
Speed
1m per second
Waiting interval
less than 10 seconds

4.0
Population densities

Air conditioning
1 person/7.5m
Means of escape
1 person/7.5m
Lifts
1 person/7.5m
Toilets
1 person/7.5m

5.0
External design
conditions

Summer
-4c db saturated
Winter
29c db/20c wb

6.0
Parking

Car parking
Available by arrangement
Bicycle parking
Available
Showers
1 per floor
